The branch breakers protect the wires leading to individual electrical loads such as fixtures and outlets. Eatons meter breakers combine a single meter socket and a main circuit breaker and/or loadcenter into one enclosure. The main breaker protects the main entire panel and can be used as a service disconnect. The panels serve as main breaker for service entrances.
It uses a 2-pole breaker.Specially designed for easy installation, Eaton's BR load centers house the branch circuit breakers and the wiring required to distribute power to individual circuits. Therefore I have assumed you're dealing with a 240V load like a dryer that uses two (opposite) 110V circuits at the same time to get 240V. The Eaton BR Circuit Breaker Hold-down Screw Kit secures a double-pole circuit breaker to the main load center in back-feed main. Just learn how loads work and act smartly, don't just overload to the point of a house fire. Don't misuse a 30A breaker where a 15A or 20A breaker should be used, like powering common lighting and receptacle circuits. The only legitimate use I have seen is in TT30 sockets for small travel trailers. Wait, did you say 110V?Ī 110/120V circuit that is 30A is extremely rare. Label the socket "GFCI Protected / No Equipment Ground". If you absolutely, insist on wiring it 3-wire without ground, then still use a NEMA 14-30 socket and plug, and fit a 2-pole GFCI breaker in the panel.
EATON BR 200 AMP BREAKER INSTALL
However, if your appliance comes with a NEMA 6-30 plug, you are allowed to install a NEMA 6-30 receptacle instead of 14-30 it'll be grounded and you won't use the neutral. If you are hooking up a dryer and the dryer came to you with a NEMA 10-30 cord and plug, then change the cord and plug to NEMA 14 while removing the neutral-ground jumper on the dryer. You are not allowed to install the obsolete/dangerous NEMA 10-30 (3-prong) which has no ground. If this is going to a receptacle, it needs to be a NEMA 14-30 (4-prong) type receptacle. Then ground to the panel chassis or a ground bar (which would be empty), you can buy retrofit ground bars for most panels for $5-ish. It is suitable for use with 2-Pole BR circuit breaker, 1-Phase 125 to 200-Amp main lug plug. This happens when the wiring is done in metal conduit, and the grounding is via the metal conduit. Eaton Hold-down screw kit measures 7.75-Inch x 5-Inch x 1-Inch.
In some cases there is a neutral and not a ground bar. Current Rating 200 Amp Circuit Configuration 1-Phase 3-Wire Maximum Number of Circuits 60 Maximum Number of Spaces 30 Main Breaker Type BR Breaker Mounting. DO NOT DO THIS unless you see all other circuits also doing this!
In some cases, the neutral bar will be the same thing as the ground bar, and all neutrals and grounds will be clumped onto the same bar. There will be a bunch of other white wires also going to this bar. The neutral bar is a closely packed row of screws which capture wires underneath them. If it's a 2-pole plain breaker, the neutral goes to the neutral bar. BR 200 Amp 80-Circuit Indoor Main Breaker Plug-On Neutral Load Center (4) Questions & Answers (2) + Hover Image to Zoom 228 36 Pay 203.36 after 25 OFF your total qualifying purchase upon opening a new card.If it's a 2-pole GFCI breaker, the neutral goes to the breaker, and the breaker pigtail goes to the neutral bar. MLO Load Center Flush/Surface Fit Eaton 200 Amp 30-40 Circuit Panel 120/240V Single Phase 200A Panel Aluminum Bus.
